Tenda IC7-LRS 4 Megapixel Network Camera - Colour - 30 m Infrared Night Vision - H.265, H.264 - 2560 x 1440 - 4 mm Fixed Lens - Wall Mount, Surface Mount

Our Product No :   46136

MPN Number :   IC7-LRS-4

Manufacturer :  Tenda Technology Inc

Model No :   IC7-LRS



General Information
Manufacturer Tenda Technology Inc
Manufacturer Part Number IC7-LRS-4
Manufacturer Website Address
Brand Name Tenda
Product Model IC7-LRS
Product Name 4MP Conch Security Camera
Marketing Information

Clear monitoring details from 4MP UHD images

Equipped with a high-performance image sensor, the camera can display 4MP UHD images (2560x1440) with more monitoring details.

Super photosensitive ability, better performance in low light

Using a high-sensitivity sensor, the camera is more light-sensitive than common cameras and can display finer images than common infrared cameras.

Remote audio pickup over 5 m supported by the inbuilt highly sensitive microphone

With an inbuilt highly sensitive microphone which supports remote audio pickup over 5 m, the camera can sync audio and video.

Multi-terminal real-time monitoring for light of heart

The camera supports remote monitoring on the PC and app, with easy and convenient operations and management.

H.265 coding technology for smooth video and efficient data storage

Compared with H.264, the new-generation H.265 saves 50% in video data size, which further smoothes the videos with band width saved and saves the data storage space.

Intelligent WDR and 3D DNR for clear images

The camera uses WDR technology which compensates for backlighting on backlit images and 3D noise reduction technology which reduces image noise to display clear monitoring video.

Wall-mounted or surface-mounted installation

The camera can be either wall-mounted or surface-mounted, quite flexible and convenient.

Product Type Network Camera
Technical Information
HD Recording Yes
Night Vision Yes
Night Vision Distance 30 m
Night Vision Type Infrared
Display & Graphics
Colour Supported Colour
Effective Camera Resolution 4 Megapixel
Video Formats
  • H.265
  • H.264
Maximum Video Resolution 2560 x 1440
Lens Type Fixed
Maximum Focal Length 4 mm
Maximum Aperture f/2.2
Network & Communication
Connectivity Technology Wired
Remote Management Yes
Network (RJ-45) Yes
Physical Characteristics
Mount Type
  • Wall Mount
  • Surface Mount
Weight (Approximate) 300 g
Environmental Conditions
Minimum Operating Temperature -10°C
Maximum Operating Temperature 50°C
Operating Humidity 95%
  • Motion Detection
  • 3D Noise Reduction
  • Alarm Detection
  • Digital Wide Dynamic Range (D-WDR)
  • Back Light Compensation (BLC)
  • Region of Interest
  • Human Detection
  • Built-in Microphone
Package Contents
  • Security Camera
  • Wall-mounted Accessory Kit
  • Quick Installation Guide
  • General Public License Notice
Environmentally Friendly Yes
Environmental Certification RoHS

Download specs Sheet
